Brass Ball Valve / FF / PN25

Brass Products

Product Description

BVFF-25 is a high-quality brass ball valve that allows fluid to flow with minimal resistance, thanks to its full-bore design. It is designed for the PN25 pressure class, offering good resistance to corrosion, which enhances its durability and reliable performance. Made from brass raw material, this valve offers an excellent solution for flow control in water and other environments, promising leak-proof operation and long life even under high pressure.

General Features

  • Threaded connection (FF) / 2-piece
  • Sizes range from DN15 (1/2’’) to DN100 (4’’)
  • Precise flow control and full bore
  • Maximum working pressure range: PN25
  • Body: Brass (CW617N) + Nickel plated
  • Bonnet: Brass (CW617N) + Nickel plated
  • Ball: Brass (CW617N) + Chrome plated
  • O-Ring: EPDM- NBR material
  • Handle: Galvanized steel + Vinyl coated
  • Gasket: High-quality sealing components (PTFE)
  • Operating temperature range: -10 ºC / +120ºC
  • Long life and high durability

Application Areas

  • Domestic Water Systems
  • Heating and Cooling Systems
  • Fire Extinguishing Systems
  • Building Management Systems
  • Water Treatment Systems
  • Various Industrial and Commercial Applications

Technical Specifications

Design Standard

TS EN 13547

Thread Standard

EN ISO 228-1

Tests

TS EN 12266-1
